You can rest assured of buying Fuel Supersonic Spraying Equipment from our factory. Suzhou Almac Machinery Equipment Co., Ltd. is a technology innovation enterprise specializing in equipment manufacturing and research and development.
Almac-JP8800 Fuel supersonic spraying equipment control cabinet
The Almac-JP8800 supersonic spraying equipment control cabinet is the control center of the system. It uses the latest technology to automatically control the entire system. It uses a touch control terminal that integrates operation, setting, help, display, process and fault alarm monitoring, making it more convenient to use and simpler and more intuitive to operate.
Almac-JP8800 Parameter Table of Fuel Supersonic Control Cabinet
Number
Project
Basic parameters
1
Control type
Control touch screen+MFC+PLC control
2
Input power
550W
3
Kerosene pressure/flow rate
1.3Mpa 22-24L/h
4
Oxygen pressure/flow rate
1.6Mpa 25-40m³/h
5
Carrier gas pressure/flow rate
0.35-0.4Mpa 1-1.4m³/h
6
External dimensions of control cabinet
500x550x1064mm
7
Control cabinet weight
59KG
Powder feeder
The Almac-JP8800 supersonic high-speed flame spraying powder feeder is a device used to store spraying powder and deliver it to the spray gun according to process requirements; Using nitrogen or argon as the powder feeding gas, the sprayed powder reaches the powder outlet with the rotation of the bottom powder feeding scraper, and enters the spray gun together with the powder feeding gas; The speed of powder feeding can be adjusted by adjusting the potentiometer on the control cabinet panel.
Almac-JP8800 Parameter table of powder feeder for fuel supersonic spraying equipment
Number
Project
Basic parameters
1
Powder delivery method
Scraper pneumatic type
2
Double tube capacity
7.0L
3
Sending powder gas
Nitrogen or argon
4
Powder delivery air pressure
0.45Mpa
5
Nitrogen pressure and flow rate
0.6-1.0Mpa 1.0-1.4m³/h
6
Powder feed rate
0~150g/min
7
Powder delivery accuracy
±1%
8
External dimensions of powder delivery gas
500x400x1300mm
9
Weight of powder feeder
50KG
Cooling system
The dual compressor drive reduces the overall volume of the machine and increases your space; Mainly used to effectively cool the nozzle and sealing ring, achieving the purpose of prolonging the service life of the nozzle and sealing ring.
Parameter table of cooling system for fuel supersonic spraying equipment
Number
Project
Basic parameters
1
Unit appearance
2330x1000x1720(mm)
2
Circulating water tank capacity
530L
3
Refrigeration capacity
76.8KW
4
Fluctuations in outlet water temperature
5-35℃
5
Power supply
3P AC380 50HZ/60HZ
6
Compressor
Dual compressor
Origin: Sanyo, Japan
7
Outlet pressure
4-10KG adjustable
Effluent flow rate
6m³/h
8
External circulation pump
Rated power 1.1KW
Rated current
1.5A
9
Refrigerant injection amount
15KG
Refrigeration media
F22
10
Fan power
85Wx2
11
Total input power
26KW
12
Weight
1500KG
Almac-8000 Fuel spray gun
The Almac-8000 fuel supersonic flame spray gun uses aviation refined kerosene as fuel, oxygen as combustion supporting gas, air and water as cooling coal, and nitrogen for powder feeding. The spray gun can work continuously and stably for a long time.
